EC4-Br2-5 Bromine Gas Electrochemical 3 Electrode Sensor
The EC Sense performance data stated above is based on data obtained under test conditions using the EC Sense gas distribution system and AQS
In the interest of continuous product improvement, EC Sense reserves the right to change design features and specifications without
We are not responsible for any loss, injury or damage caused by this. EC Sense assumes no responsibility for any indirect loss, injury or damage.
Datasheet:
Resolution (16Bit ADC) < 0.01ppm
Response Time T50 < 20s, T90 < 60s
Repeatability 2%
Lower Detectable Limit (LDL) < 0.05ppm
Linear Range 5ppm
Operating Temperature Range -20 to +40℃
Operating Humidity Range 15-95 %RH
Operating Pressure Range 800 to 1200 hPa
Storage Temperature 0 to 20℃
