NMB15-30GM55-E2 New Pepperl+Fuchs Inductive Sensor
  • NMB15-30GM55-E2 New Pepperl+Fuchs Inductive Sensor
  • NMB15-30GM55-E2 New Pepperl+Fuchs Inductive Sensor

NMB15-30GM55-E2 New Pepperl+Fuchs Inductive Sensor

  • Model: NMB15-30GM55-E2
  • Units in Stock: 17

$169.00

QTY: Unit(s)

Product Description

Switching function Normally open (NO)
Output type PNP
Rated operating distance 15 mm
Installation flush (Requirements: see drawing below)
Output polarity DC
Assured operating distance 0 ... 12.15 mm
Actuating element Ferrous and nonferrous targets
Reduction factor rAl 0.4
Reduction factor rCu 0.2
Reduction factor r304 0.85
Reduction factor rSt37 1
Output type 3-wire
Nominal ratings
Operating voltage 10 ... 30 V DC
Switching frequency 0 ... 150 Hz
Hysteresis 3 ... 15 typ. 10 %
Reverse polarity protection reverse polarity protected
Short-circuit protection pulsing
Voltage drop ≤ 2 V
Operating current ≤ 200 mA
Off-state current ≤ 10 µA
No-load supply current ≤ 10 mA
Operating voltage indicator LED, green
Switching state indicator LED, yellow
